Z2S10
Longli
841290
Z2S10high quality rexroth type hydraulic check valve
Models Z2S are pilot operated check valves in a sandwich plate design. They provide line contact closure in one or two actuator ports, even during idle periods. Piloted to open, utilizing a pressure signal from the opposite actuator port provides a self-contained function.
Features
Sizes 6 to 22
Porting pattern according to ISO 4401-3, 5, 7, 8; NFPA T3.5.1M R1, and ANSI B93.7 D 03, D 05, D 07, D 08
For the leak-free isolation of one or two actuator ports
Various cracking pressures
Technical Parameter:
Product name | Double Throttle Check Valve |
Model | Z2S10 |
Place of Origin | Shandong, China |
Size | 10 |
Max. Flow | up to 120 L/min |
Max.Pressure | up to 31.5 Mpa |
Material | Casting |
Fluid | Mineral oil or Phosphate ester |
Temperature range | -30-+80℃ |
Power | Hydraulic |
Weight | 0.8KG |
Color | Customer's request |
Certificate | ISO9001 |
